Laboratory Hotplate is Glass ceramic and 184x184mm plate.The temperature is 0-550C. temperature can be displayed on screen.
External temperature control is possible by connecting temperature sensor PT1000 with an accuracy of ±0.2℃
Screen will display actual and accurate temperature .
ceramic coating work plate provides excellent chemical resistant performance and most efficient heat transfer
temperature can be displayed on screen.
| Model | HP-550 |
| Work plate Dimension | 184x184mm(7 inch) |
| Work plate material | Glass ceramic |
| Heating position | 1 |
| Heating temperature range | Room Temp.-550℃, increment 5℃ |
| Temperature control accuracy | ±10℃ |
| Temperature display accuracy | ±1℃ |
| Over heat Protection | 580℃ |
| Display | LED(Temperature display) |
| External temperature sensor | PT1000 ( accuracy±0.2℃ ) |
| Heating warning | 50℃ |
| Protection class | IP21 |
| Heating Power | 1000W |
| Timer function | --- |
| Power | 100-120/200-240V 50/60Hz |
| Dimension[WxDxH] | 215x360x112mm/4.5kg |
